Brixwell Top Or Bottom Mount Pivot Hinge Brass, Brushed Bronze Finish, for 5/16" to 3/8" Glazing Thickness, Head and Sill Mount, Full Rotation, Self Centering, Beveled Edge

BRIXWELL

MATERIAL: Made from brass to support pivot hinge operation for glass doors. The material supports head and sill mounting while transferring most door weight to the bottom mount during floor pivot movement and full rotation swing use. FINISH: Brushed bronze finish provides a muted surface tone that blends with common bathroom and interior glass hardware layouts while maintaining a consistent appearance across pivot hinge and enclosure components. GLASS COMPATIBILITY: Designed for tempered safety glass with thickness from 5/16" to 3/8". The hinge supports frameless glass door installations requiring pivot floor opening and controlled door movement. DOOR MOVEMENT: Full rotation pivot swing supports flexible opening movement using a floor based pivot style. The design allows glass panels to be inset from the wall for added clearance near projections. SELF CENTERING ACTION: Self centering mechanism uses internal springs to guide the door back toward the closed position after opening, helping maintain consistent alignment during daily repeated operation. DIMENSIONS: Hinge measures 2" height, 3-5/8" overall length. Back plate width is 13/16" with a 5/16" back plate thickness. Glass clearance measures 1/8", allowing proper spacing between the glass panel and surrounding surfaces. INSTALLATION DETAILS: Supports glass doors up to 31" wide with a maximum door weight of 100 lbs when two hinges are used. Supplied with gaskets, cross head screws, hex screws, and an installation template to support accurate positioning., Weight: 1.5 Pounds, Manufacturer: Brixwell
