7"" CLAA070MA0ACW 800X480 LCD Screen VGA CVBS LCD Controller Board

--\n\n--\n\n--\n\n--\n\nProduct Description\n\nLCD Controller Board:\nVGA 2AV LCD Board Work for 50Pin and 60Pin TTL LCD Screen\nInput Power Adapter:12Vdc More than 2A.\nCome In Standby Model When Not Input Signal\nStandby Model <1W\nVideo Input: VGA AV1 AV2\nReversing: Support Automatically Switch To AV2 When Connector ACC to 12V\nOSD: Brightness Contrast Auto Language And So On\nLanguage: English French German Spanish Italian And So On\nBoard Size:90mm x 70mm x 12mm\n\n7\"" LCD Screen CLAA070MA0ACW:\nDisplay Mode N, Normally White, Transmissive\nResolution 800RGB)\u00D7600\nOutline Size 154 \u00D7 119.2 \u00D7 5.4 (H\u00D7V\u00D7D)\nDisplay Area 141.6 \u00D7 106.2 (H\u00D7V)\nBrightness 250 cd/m\u00B2 (Typ.)\nContrast Ratio 500:1 (Typ.) (TM) \nViewing Angle 70/70/50/70 (Typ.)(CR\u226510) [Left / Right / Up / Down]\nSignal Interface TTL (1 ch, 6/8-bit) , FPC , 60 pins\nBacklight WLED\nInput Voltage 3.3/9.6/18/-6V (Typ.)(VCC/AVDD/VGH/VGL)\n\nPacking list:\n1\u00D7y
