6.5"" 640X480 400nit T-51750GD065J-FW TFT LCD Screen VGA Control Board 31 pins
--\n\n--\n\n--\n\n--\n\n--\n\nProduct Description\n\nLCD Controller Board: \nVGA LCD Board Work for LVDS Interface LCD Screen\nInput Power Adapter:12Vdc More than 2A.\nCome In Standby Model When Not Input Signal\nStandby Model <1W\nVideo Input: VGA\nOSD: Brightness Contrast Auto Language And So On\nLanguage: English French German Spanish Italian And So On\nBoard Size:107mm x38mm x 18mm\n6.5\"" T-51750GD065J-FW 640X480 LCD Screen:\nDisplay Mode TN, Normally White, Transmissive \nResolution 640(RGB)\u00D7480\nOutline Size 158 \u00D7 120.36\u00D711.2 (H\u00D7V\u00D7D)\nDisplay Area 132.48\u00D7 99.36 (H\u00D7V) \nBrightness 400 cd/m\u00B2 (Typ.)\nContrast Ratio 300:1 (Typ.) (TM)\nViewing Angle 55/55/30/60 (Typ.)(CR\u226510) [Left / Right / Up / Down]\nSignal Interface Parallel RGB (1 ch, 6-bit) , 31 pins Connector \nBacklight 2CCFL\nInput Voltage 3.3V /5.0V(Typ.)\n\nPacking list :\n1\u00D7 VGA LCD Controller Board RT2270C-806\n1\u00D7 6.5inch T-5175y
Compare prices (1 shop)
| shop | Price | Action |
|---|---|---|
|
70,80 GBP | Go to shop |
