Blue Sea Systems - Auto Charging Relay - 65 Amp - VSR - M-ACR - Part no. 7601

Name: Blue Sea Systems - Auto Charging Relay - 65 Amp - VSR - M-ACR - Part no. 7601
Brand: BLUE SEA SYSTEMS

BLUE SEA SYSTEMS

Blue Sea Systems 7601\nDC Mini ACR Automatic Charging Relay - 65 Amp\nFeatures:\n65 Amp continuous rating manages the charging current from alternators up to 65 Amps found on most outboards and many inboard engines \nCompact case design allows surface and panel mounting \nSenses charging on two battery banks \nSnap-on cover insulates terminal connections \nLED indicates ACR status \n1/4\"" x .032\"" male quick connect terminal for ground \n5/8\"" (16 mm) stud length to accept multiple cable terminals \n12V DC voltage input\n\nSpecifications:\nIntermittent Rating: 5 min.: 115A\nTerminal Stud Size: 1/4\""-20\nRelay Contact Position: Open (30 sec.): 12.75V DC\nContinuous Rating: 65A\nMaximum Torque: 75 in-lb (8.5 Nm)\nRelay Contact Position - Open High: 16.0V DC\nAmperage Operating Current: 175mA (Combine)\nRelay Contact Position: Combine (30 sec.): 13.0V DC\nUnder Voltage Lockout: 9.5V DC\nAmperage Operating Current: 15mA (Open)\nRelay Contact Position: C.
