Hitec D485HW Wide Voltage Standard Servo

Name: Hitec D485HW Wide Voltage Standard Servo
Brand: Hitec

Hitec

Hitec D485HW Wide Voltage Standard Servo \n\nReplacing the standard-size HS-5485HB and HS-5495BH servos, the sport class D485HW brings faster response and accuracy to your various radio control needs with D-series high resolution 32-bit technology and wide voltage operation.\n\nSpecification:\n\n--Dimensions \n1.57\"" x 0.78\"" x 1.49\"" (39.8 mm X 19.8 mm X 38.0 mm)\n\n--Product Weight \n1.59 oz (45.0 g)\n\n--Output Shaft Style \n25 tooth (H25T) spline\n\n--Voltage Range \n4.8 V - 7.4 V\n\n--No-Load Speed (4.8V) \n0.20 sec/60\u00B0\n\n--No-Load Speed (7.4V) \n0.15 sec/60\u00B0\n\n--Stall Torque (4.8V) \n67 oz-in. (4.82 kg.cm)\n\n--Stall Torque (7.4V) \n103 oz-in (7.41 kg.cm)\n\n--Max PWM Signal Range (Standard) \n850-2350 \u03BCsec\n\n--Travel per \u00B5s (out of box) \n.098\u00B0/\u03BCsec\n\n--Travel per \u00B5sec (reprogrammed) \n0.135\u00B0/\u03BCsec\n\n--Max Travel (out of box) \n147\u00B0\n\n--Max Travel (reprogrammed) \n203\u00B0\n\n--Pulse Amplitude \n3-5 V\n\n--Operating Tempe;
