STEPPERONLINE Nema23 Bipolar 0.9deg 1.2Nm Φ6.35mm 2.8A 57x56mm 4 Wires
STEPPERONLINE
--\n--\n--\n--\n--\n--\n\nDescription\n\nThis bipolar Nema 23 stepper motor with step angle 0.9deg and size 57x57x56mm. It has 4 wires, each phase draws 2.8A, with holding torque 1.26Nm (178.4oz.in).\n\nPackage Included:\n1 x Nema 23 Stepper Motor 23HM22-2804S\n\n \n\nSpecifications\n\nManufacturer Part Number\n23HM22-2804S\n\nMotor Type\nBipolar Stepper\n\nStep Angle\n0.9 deg\n\nHolding Torque\n1.26Nm(178.4oz.in)\n\nRated Current/phase\n2.8A\n\nPhase Resistance\n0.9ohms\n\nRecommended Driving Voltage\n24-48V\n\nInductance\n4.5mH\u00B120%(1KHz)\n\nFrame Size\n 57 x 57mm\n\nBody Length\n56mm\n\nShaft Diameter\n\u03A66.35mm\n\nShaft Length\n21mm\n\nD-cut Length\n15mm\n\nLead Length\n500mm\n\nWeight\n700g\n\n \n\nDetails\n\n \n \n\nWarranty and Guarantee \n\nFor 30 days after the date of purchase, return your undamaged product and receive a full refund for ANY reason.\n\n Reminder: Please contact us via eBay message when you want to return your purchase, we will;
Compare prices (1 shop)
| shop | Price | Action |
|---|---|---|
|
42,00 GBP | Go to shop |
