STEPPERONLINE Nema 23 Stepper Motor 1.26Nm D-cut Shaft 6.35mm 57x56mm 2.8A CNC

Name: STEPPERONLINE Nema 23 Stepper Motor 1.26Nm D-cut Shaft 6.35mm 57x56mm 2.8A CNC
Brand: STEPPERONLINE

STEPPERONLINE

--\n--\n--\n--\n--\n--\n \n\nElectrical Specification\n\n--Manufacturer Part Number: 23HE22-2804S\n\n--Number of phase: 2\n\n--Step Angle: 1.8deg\n\n--Holding Torque: 1.26Nm(178.4oz.in)\n\n--Rated Current/phase: 2.8A\n\n--Phase Resistance: 0.9ohms\u00B1 10%\n\n--Inductance: 2.5mH\u00B120%(1KHz)\n\n--Insulation Class: B 130\u00B0C[266\u00B0F]\n\nPhysical Specification\n\n--Frame Size: 57 x 57mm\n\n--Body Length: 56mm\n\n--Shaft Diameter: \u03A66.35mm\n\n--Shaft Length: 21mm\n\n--D-cut Length: 15mm\n\n--Number of Leads: 4\n\n--Lead Length: 300mm\n\n--Weight: 0.7kg\n\nConnection\n\nA+\n\nA-\n\nB+\n\nB-\n\nBlack\n\nGreen\n\nRed\n\nBlue\n\n \nThis motor is now available in a pack of 3. It has a better price. For more details, please see 3-23HE22-2804S.\n\n
