STEPPERONLINE 3 Axis Nema 23 Stepper Motor 3Nm &Driver DM542T for CNC Router Kit

Name: STEPPERONLINE 3 Axis Nema 23 Stepper Motor 3Nm &Driver DM542T for CNC Router Kit
Brand: StepperOnline

StepperOnline

\n\n--\n \n\n \n \n\n--\n \n\n \n \n\n--\n \n\n \n \n\n--\n \n\n \n \n\n--\n \n\n \n \n\n--\n \n\n \n \n\n3 Axis Nema23 CNC kit includes\n\n3 x Digital Stepper Drive 1.0-4.2A 20-50VDC DM542T\n\n--3 x Nema 23 Stepper Motor Bipolar 1.8deg 3.0 Nm(425oz.in) 4.2A 57x57x113mm 4 Wires\n\n--1 x 400W 36V 11A 115/230V Switching Power Supply Stepper Motor CNC Router Kits\n\nMotor Specification\n\n--Manufacturer Part Number: 23HS45-4204S\n\n--Number of phase: 2\n\n--Step Angle: 1.8 deg\n\n--Holding Torque: 3Nm(425oz.in)\n\n--Rated Current/phase: 4.2A\n\n--Phase Resistance: 0.9ohms\u00B1 10%\n\n--Inductance: 3.8mH \u00B1 20%(1KHz)\n\n--Frame Size: 57 x 57mm\n\n--Body Length: 113mm\n\n--Shaft Diameter: \u03A610mm\n\n--Shaft Length: 24mm\n\n--D-cut Shaft Length: 20mm\n\n--Number of Leads: 4\n\n--Lead Length: 500 mm\n\n--Weight: 1.8 kg\n\nConnection\n\nA+\n\nA-\n\nB+\n\nB-\n\nBLK\n\nGRN\n\nRED\n\nBLU:
