Pimoroni Tiny 2040 Microcontroller Development Board, 2Mb Flash
PIMORONI
Incredibly compact RP2040 development board with an impressive feature set that includes USB-C connectivity, 2MB flash, RGB LED and physical reset button - all with the size of a postage stamp! The Tiny 2040 can still be programmed over USB using C/C++ or Powered by the RP2040 chip and compatible with Raspberry Pi Pico firmware Dual core ARM Cortex M0+ processor running at up to 133MHz 264kB SRAM & 2MB QSPI flash with XiP support 16 GPIO pins and debug; includes 12 IO pins & 4 12-bit ADC channels User controllable RGB LED Switch for basic input, doubles as DFU select on boot USB-C for power & data (3-5.5V input) Onboard 3V3 regulator Designed with castellated pads to allow it to be directly soldered onto a PCB Pin headers can be soldered on to hook it up on a breadboard (headers not included)
Compare prices (1 shop)
| shop | Price | Action |
|---|---|---|
| CPC | 7,18 GBP | Go to shop |
