Hager ADN116 - 16a 30mA Type B Single Pole Class AC RCBO Used

Name: Hager ADN116 - 16a 30mA Type B Single Pole Class AC RCBO Used
Brand: Hager

Hager

Hager ADN116 - 16a 30mA Type B Single Pole Class AC RCBO\n\nHager Part Code: ADN116\n\nProduct Code: 106362\n\nCompact protection devices which combine the overcurrent functions of an MCB with the earth fault functions of an RCCB in a single unit.\n\nA range of sensitivity and current ratings are available for use in commercial and domestic installations.\n\nClass AC RCBO\n\nClass AC RCBOs and RCDs are suitable for all systems where users have sinusoidal earth current. They are not sensitive to impulsive leakage currents up to a peak of 250 A (8/20 wave form) such as those which may occur due to overlapping voltage impulses on the mains (e.g.: insertion of fluorescent bulbs, X-ray equipment, data processing systems and SCR controls).\n\nTechnical Data\n\nComplies with BS EN 61009/IEC1009\n\nSensitivities (fixed)\n\nBreaking capacity rated at: 6kA\n\nFlying neutral and functional earth leads: 200mm\n\nTerminal Cable Capacities: 16mm2 rigid, 10mm2flexible\n\nApplication\n\nOne module d.
