Hager ADB120 B Curve 10kA 30mA RCBO - 20 Amp

Hager ADB120 B Curve 10kA 30mA RCBO - 20 Amp

Hager

Hager ADB120-106749 - 20a 30mA Type B Single Pole Class AC RCBO\n\nHager Part Code: ADB120\n\nProduct Code: 106749\n\nCompact protection devices which combine the overcurrent functions of an MCB with the earth fault functions of an RCCB in a single unit.\n\nA range of sensitivity and current ratings are available for use in commercial and domestic installations.\n\nTechnical Data\n\nClass AC RCBO\n\nClass AC RCBOs and RCDs are suitable for all systems where users have sinusoidal earth current. They are not sensitive to impulsive leakage currents up to a peak of 250 A (8/20 wave form) such as those which may occur due to overlapping voltage impulses on the mains (e.g.: insertion of fluorescent bulbs, X-ray equipment, data processing systems and SCR controls).\n\nSensitivities (fixed)\n\n20A - 30mA - 230/240V - Type B Curve - Single Pole\nBreaking capacity rated at: 6kA\n\nFlying neutral and functional earth leads: 200mm\n\nTerminal Cable Capacities: 16mm2 rigid, 10mm2 flexible\n\nAppl.

Compare prices (2 shops)

Sort: Price: lowest first Price: highest first
shop Price Action
34,60 GBP Go to shop
43,55 GBP Go to shop
