5x24 surface-mounted modular switchboard IP30 FW524WT /T2UK

Name: 5x24 surface-mounted modular switchboard IP30 FW524WT /T2UK
Brand: HAGER POLO

HAGER POLO

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\n5x24 surface-mounted modular switchboard IP30 FW524WT /T2UK\nParameters:\n\n--CN: 85381000\n-- PKWiU: 27/12/40.0\n-- Degree of protection (IP): IP30\n-- Mounting method: Surface mounting\n-- White color\n-- Housing material: Steel\n-- DIN rail: Yes\n-- Cover type: Closed\n-- Height [mm]: 941\n-- Depth [mm]: 150\n-- Width [mm]: 571\n-- RAL number: 9010\n-- Width expressed in the number of modules: 24\n-- Number of rows: 5\n\nThe modular switchgear is part of the FW2 series and contains 5 rows with 24 modules on each of them. It is a product that includes: an assembly grid, a door, a metal cover and a set of PE/N screw terminals, which are mounted on a special bracket. The installed switchgear has the following dimensions: 950 mm high, 550 mm wide and 110 mm deep, which allows it to be mounted surface-mounted on most walls in public buildings. The product is made of resistant steel sheet, protected withS
