ABB OVR-T1-T2-3N-12.5-275S-P-TS-QS Surge arrester

Name: ABB OVR-T1-T2-3N-12.5-275S-P-TS-QS Surge arrester
Brand: ABB

ABB

PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nSurge arrester; Type 1+2; Poles: 3+N; In 8/20us: 80kA; -40\u00F780\u00B0C\nABB\nMPN: OVR T1-T2 3N 12.5-275S P TS QS\nEAN: 3660308524928\nRated voltage: 230/400V AC\nMax. operating voltage: 275V AC\nProtection level at rated imp. current: 1.3kV\n\nPrice per 1 pc\nTechnical parameters\nParameterValue\nOperating temperature-40...80\u00B0C\nRated voltage230/400V AC\nMax. operating voltage275V AC\nProtection level at rated imp. current1.3kV\nRated impulse current In (10/350)\u00B5s12.5kA\nRated impulse current In (8/20)\u00B5s80kA\nIP ratingIP20\nKind of networkTT\nMountingfor DIN rail mounting\nIntegrated auxiliary contactsNO + NC\nType of protectionsurge arrester\nKind of surge arresterType 1+2\nSurge arresters featuresfitted with mechanical indicators of each arrester operation\nNumber of poles3+N\n\nWeight: 626 g\n\nService and information\n\nQuantity\nNot all available quantities are v.
