KALEA-INFORMATIQUE PCIe 3.1 SAS + SATA + NVMe 12GB 16-port internal controller card. OEM model 9400-16i
KALEA-INFORMATIQUE
The card comes in an "OEM" version, i.e. in a neutral box and with drivers that can be downloaded from the LSI website (www.broadcom.com). It can be used to add 16 internal SAS ports to a PC or server via an 8x (or 16x) PCIe 3.1 (or higher) connector. Benefits: Supports up to 16 SAS or SATA drives, NVMe SSD compatible. PCIe 3.1 x8, Compatible with HDD, SSD and NVMe SSD, High performance, with transfer rates of 12GB/s and multiple SAS cores. SAS 3416 controller. 16 internal ports via 4 Mini SAS HD SFF8643 connectors, each supporting 4 drives. SAS 3.0 compatible 12Gb/s data transfer rate. Maximum NVMe support: 4 x 4 SSDs or 8 x 2 SSDs. Maximum number of devices supported: 1024 SATA or SAS HDDs / 24 NVMe SSDs. PCIe 3.1 type 8x bus. Dimensions: 155.65 mm x 68.90 mm. Form factor: Low Profile, supplied with Low and High Profile brackets. Passive Copper connector support. Operating voltage +12V +/-8%; 3.3V +/-9%. Power consumption 11.95W. Environment: operating from 0°C to 55°C, storage from -45°C to 105°C, RH 5 to 90%. Service life in excess of 4,500,000 hours. Compatible with the following OS: Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SuSE Linux, Ubuntu Linux, Citrix XenServer, CentOS, Linux, Debian Linux, Oracle Enterprise Linux, Fedora, and FreeBSD.
Compare prices (1 shop)
| shop | Price | Action |
|---|---|---|
|
278,53 GBP | Go to shop |
