Simonswerk TE240 Tectus 3D HINGE MATT NICKEL 155X50.7X27MM

Name: Simonswerk TE240 Tectus 3D HINGE MATT NICKEL 155X50.7X27MM
Brand: Simonswerk

Simonswerk

Simonswerk TE240 Tectus 3D HINGE MATT NICKEL 155X50.7X27MM\n\nMaintenance free friction bearings\nSuitable for left or right hand applications\n\nMountingFor DIN left and DIN right hand use \n\nFlange shaperounded \n\nFlange width18 mm\u200A/\u200A21 mm \n\nMaterial\n\nModelTE 240 3D \n\nFlange height155 mm \n\nModel series\n\nTECTUS TE 240 3D\n\nArea of application\n\nFor wooden, steel or aluminium frames\nFor flush doors\n\nFor frame type\n\nSteel frame, Wooden frame, Aluminium frame\n\nMax. door weight for 2 hinges\n\n40.00 kg\n\nOpening angle\n\n180.00 \u00B0\n\nDoor thickness\n\n\u226525 mm\n\nRouter bit \u00D8\n\n16.00 mm\n\nThrust ring \u00D8\n\n30.00 mm\n\nBearing type\n\nFriction bearing, maintenance-free\n\nAdjustment facility\n\n3D, Side: \u00B13 mm, Height: \u00B13 mm, Closing pressure: \u00B11.5 mm \n\nFinish- Matt Nickel forend plates (main body which is concealed is black)
