DOGA 162.4101.30.00 24V DC Motor 3000rpm 0.20Nm

Name: DOGA 162.4101.30.00 24V DC Motor 3000rpm 0.20Nm
Brand: Doga

Doga

A brushed DC motor from the DOGA 162 series, ideal for variable speed applications.\n\n--Nominal voltage 24V DC\n--Nominal current 4A\n--Nominal torque 0.2Nm\n--Nominal speed 3000rpm\n--Shaft diameter 8mm\n--Shaft style: flattened to 6.4 x 12mm\n--Protection rating IP53\n--DOGA type 162.4101.30.00\n\n--\nOur eBay Store\n\nPlease note: This item has a longer lead time for dispatch then normal as it's a non-stocked item that is ordered in, please see the estimated delivery date by eBay. We will of course ship the item sooner if possible.\n\nDOGA 162.4101.30.00 24V DC Motor 3000rpm 0.20Nm\n\nProduct Details\n\nA brushed DC motor from the DOGA 162 series, ideal for variable speed applications. \n\n--Nominal voltage 24V DC\n--Nominal current 4A\n--Nominal torque 0.2Nm\n--Nominal speed 3000rpm\n--Shaft diameter 8mm\n--Shaft style: flattened to 6.4 x 12mm\n--Protection rating IP53\n--DOGA type 162.4101.30.00 \n\nNameValueMaximum Continuous Torque0.2NmNominal Speed3000rpmRated Load Current4A;
