Honeywell T100R-AA0H- specialized thermostatic mixing and diverting actuator

Honeywell

--Honeywell T100R-AA0H- specialized thermostatic mixing and diverting actuator\n--\n\n--The Honeywell Resideo T100R-AA0H is a specialized thermostatic mixing and diverting actuator designed to automatically control water temperature. \n--It functions without needing any external energy source. \n--Instead, it utilizes a liquid-filled remote sensor that expands or contracts based on fluid temperature to mechanically open or close a connected valve\n--\n\n--Technical Specifications\n--Connection Thread: Standard M30 x 1.5 connection.\n--Closing Dimension: 11.5 mm\n--Immersion Pocket: None included (the 0H suffix indicates this variant is sold without an immersion pocket).\n--Temperature Adjustment Range: 10\u00B0C to 50\u00B0C (50\u00B0F to 122\u00B0F).\n--Maximum Flow Temperature: 120\u00B0C (248\u00B0F).\n--Maximum Operating Pressure: 10 bar (145 psi)\n--.Capillary Tube Length: 2 meters (6' 8\"")\n--\n\n--Key Features & Design\n--Self-Actuating Operation: Operates compleE
