Weidmüller Weidmuller 1782300000 ZDLD Series Brown, 2.5mm², Triple-Level, Clamp Termination

Name: Weidmüller Weidmuller 1782300000 ZDLD Series Brown, 2.5mm², Triple-Level, Clamp Termination
Brand: Weidmüller

Weidmüller

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nConnector ZDLD 2.5-2N 1782300000 /T2UK\nParameters:\n\n--Mounting method: DIN 35 mm mounting rail\n-- Beige colour\n-- Type of insulating material: Thermoplastic\n-- Flammability class of insulation material acc. UL 94:V0\n-- Inner floors bridged: No\n-- Type of electrical connection 1: Spring terminal\n-- Type of electrical connection 2: Spring terminal\n-- Connection position: Top / top\n-- Explosion-proof version \""EEx e\"": No\n-- Closing plate required: Yes\n-- Insulating element material: Thermoplastic\n-- Cross-section of the connected single-wire cable [mm2] from: 0.5\n-- Cross-section of the connected single-wire cable [mm2] to: 2.5\n-- Cross-section of the connected stranded wire without ferrule [mm2] from: 0.5\n-- Cross-section of the connected stranded wire without ferrule [mm2] to: 1.5\n-- Operating temperature range [\u00B0C] from: -50\n-- Operating temperature range [\u00B0C] up to: 120\S
