Installation Cable H05V-K 1x0.75 Red 4510042S/250m

PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nInstallation cable H05V-K 1 x 0.75 red 4510042S/250 m\nUnbranded\nMPN : 4510042S\nEAN: 4044773395327\nRated Voltage U0: 300\nApproximate Outside Diameter: 2,7000\nRated Voltage U: 500\n\nPrice per 1 ring (250 m)\nTechnical parameters\nParametersValue\nPermissible temperature of the fixed cable [\u00B0C] to80\u00B0C\nPermissible temperature of the fixed cable [\u00B0C] from30\u00B0C\nPermissible cable temperature for moving connections [\u00B0C] to70\u00B0C\nPermissible cable temperature for moving connections [\u00B0C] from5\u00B0C\nRated voltage U0 [kV]300 kV\nNominal cross section of core [mm\u00B2]0.7500 mm\u00B2\nApproximate Outer Diameter [mm]2,7000mm\nRated voltage U [kV]500 kV\nApproximate Cable Weight [kg/km]12kg/km\nLow temperature resistant (according to EN 60811-1-4)No\nLow smoke emission (according to EN 61034-2)No\nOil-resistant (according to EN 60811-2-1)No\nHalogen-free .
