Rail Connector 4 Core 2.5mm² Red 2002-1403 TOPJOBS

Name: Rail Connector 4 Core 2.5mm² Red 2002-1403 TOPJOBS
Brand: WAGO

WAGO

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\n4-wire rail terminal block 2.5mm2 red 2002-1403 TOPJOBS /T2UK\nParameters:\n\n--CN: 85369010\n-- Mounting method: 35 mm DIN mounting rail\n-- Red colour\n-- Type of insulating material: Thermoplastic\n-- Flammability class of the insulating material according to UL94: V0\n-- Internal floors bridged: No\n-- Electrical connection type 1: Spring clamp\n-- Electrical connection type 2: Spring clamp\n-- Connection Position: Top/Up\n-- Explosion-proof version \""EEx e\"": Yes\n-- Locking Plate Required: Yes\n-- Cross-section of the connected single-wire cable [mm2] from: 0.25\n-- Cross-section of the connected single-wire cable [mm2] up to: 4\n-- Cross-section of the connected stranded cable without ferrule [mm2] from: 0.25\n-- Cross-section of the connected stranded cable without ferrule [mm2] up to: 4\n-- Cross-section of the connected multi-core cable [mm2] up to: 4\n-- Operating temperature range [\u00B0CS
