Ganter Normelemente GN 717-8-M12-AK-ST Locking Bolt, Silver, Pack of 2
Ganter Normelemente
Locking distance l1: 8 mm; thread length l2: 24 mm; bolt diameter d1: 8 mm; thread d2: M12; hex length l3: 9 mm Box contents: 2 locking bolts Form AK: with pull ring, with lock nut Guide (threaded part): galvanised steel, blue passivated, locking pin: stainless steel (1.4305); compression spring/pull ring: stainless steel stainless steel (1.4310) Max. Tightening torque in Nm: 20; spring pressure in N: 6 (beginning) - 22 (end), Manufacturer: Ganter Normelemente
