Festo Mini-Slide DGSL-16-50-PA 543987

Name: Festo Mini-Slide DGSL-16-50-PA 543987
Brand: Festo

Festo

Festo Mini Sled Dgsl-16-50-pa 543987The description of this item has been automatically translated. If you have any questions, please feel free to contact us.\n\nUntitled_1\n\nFesto\n\nmini slide\n\nType: DGSL-16-50-PA 543987\n\n Used, from a warehouse clearance\n\nHup to 50 mm\nAdjustable end position range / front length 37.5 mm\nAdjustable end position range / rear length 39.5 mm\nPiston \u00D820 mm\nOperating mode of the drive unit yoke\nDamping-elastic damping rings/plates on both sides\nAny installation position\nGuideBall cage guide\nStructural design yoke piston piston rod slide\nPosition detection for proximity switches\nIcon00991263\nWorking Pressure0.1MPa... 0.8MPa\nOperating pressure1 bar ... 8 bars\nMax. Speed \u200B\u200B0.8 m/s\nRepeatability0.3 mm\nFunctionalitydouble-acting\nOperating medium compressed air according to ISO 8573-1:2010 [7:4:4]\nNote on the operating/control medium Oiled operation possible (required for further operation)\nCorrosion resistance cla1
