TIME-SERT® M11 x 1.5 x 16mm Thread Repair Insert – Würth

Name: TIME-SERT® M11 x 1.5 x 16mm Thread Repair Insert – Würth
Brand: Time Sert

Time Sert

1 x TIME SERT\u00AE M11 x 1.5 x 16mm INSERT 16mm length for - Thread Repair\n\n--QUANTITY - 1 x INSERT\n--M11 x 1.5\n\n--Length - 16mm\n\n--ID - 11mm x OD - 12.58mm\nTIME-SERT\u00AE is a solid bushing insert which guarantees easy installation and allows for full load use of a tapped hole, ensuring protection against stress and vibration. \n\nTIME-SERT\u00AE is thin walled due to synchronized internal external threads. \n\nIts thin cross-sectional area allows for installation in areas of limited space and clearance material. \n\nHaving a flange on the top of the insert will insure that the insert will have positive placement and cannot wind down into the newly repaired hole. \n\nTIME-SERT\u00AE is self locking. \n\nOn installation the bottom internal threads of the insert are cold rolled to expand the mating external threads into the base material, thus locking the insert in place. \n\nThe locking mechanism is at the bot.
