Wago Green Eco 2 Ac/Dc Din Rail Power Supply, 1 Phase, 24V Dc, 2.5A, 60W

Name: Wago Green Eco 2 Ac/Dc Din Rail Power Supply, 1 Phase, 24V Dc, 2.5A, 60W
Brand: WAGO

WAGO

2687-2143 is an Eco 2, 1-phase power supply. It features natural convection cooling when horizontally mounted. Suitable for both parallel and series operation. Electrically isolated output voltage ((SELV/PELV) per EN 61010/UL 61010. Meets EN 61010-1, EN 6 24VDC output voltage, 2.5A output current, DC-OK LED Marker slot (2789-1223, not included) for WAGO marking cards (WMB) and WAGO marking strips 1 x AC 100 to 240V nominal input voltage Ui nom 1 x LED DC OK (green) signalling Efficiency (typ) is 88% and isolation voltage (pri.-sec AC) is 3510V Protection class II, protection type IP20 per EN 60529 Short-circuit-protection, open-circuit-proof, parallel and series operation Push-in CAGE CLAMP® connection technology, DIN-35 rail screw mounting type Ambient temperature (operation) range from -25 to 70°C (device starts at ?’40 °C (type-tested))
