MOBLOCK 4P 160A-9 1X50 + 2X35 + 6X16MM² BLOCK MAB4160A18

PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nMOBLOCK 4P 160A-9 1X50 + 2X35 + 6X16MM\u00B2 DISTRIBUTION BLOCK\nMorek\nMPN : MAB4160A18\nEAN: 4744397013644\nWidth: 99\nHeight: 54\nMaximum Rated Current: 160\n\nPrice per 1 pc\nTechnical parameters\nParametersValue\nETIM ClassDistribution module with terminals\nETIM GroupPower Distribution Systems / Switchgear\nWidth99\nHeight54\nDepth131\nNumber of Poles4\nNumber of Terminals Per Pole9\nFlex cable cross section with sleeve tip1.5\nRigid wire cross section (single wire, multi wire)1.5\nMaximum Rated Current160\nPCN85369010\nMinimum Order Quantity1.00\n\nProduct Description\n\nThe Moblock series distribution blocks offered by MOREK are used in low-voltage control cabinets or control cabinets. Offered in bipolar, 1-phase (up to 35mm 2 and 125A, AC/DC 1000V rated voltage)) and four-pole, 3-phase (up to 50mm 2 and 160A). The terminal blocks are located on insulated supports and are cover.
