Fitting OTL95 Red 1xAl/Cu MAA CLAMPS MAA1095R10
MOREK
PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nCoupling OTL95 red 1xAl/Cu 6-95mm\u00B2 1000V AC/1500V DC universal terminal MAA1095R10\nMOREK\nMPN : MAA1095R10\nEAN: 4744397013897\nLength: 84\nRated Voltage: 1500\nRated Current In: 245\n\nPrice per 1 pc\nTechnical parameters\nParametersValue\nColourRed\nType of InsulationThermoplastic\nFlammability class of the insulation material according to UL94V0\nType of Electrical Connection 1Fitting\nConnection PositionSide / Side\nLocking plate requiredNo\nInsulating MaterialThermoplastic\nCross section of the connected single wire cable [mm2] from6mm\u00B2\ncross section of the connected single wire cable [mm2] to95mm\u00B2\nLength [mm]84mm\nRated Voltage [V]1500V\nOperating Temperature Range [\u00B0C]80\u00B0C\nCross section of connected single wire cable [mm2]95mm\u00B2\nRated Current In [A]245A\nNumber of Levels1\nWidth / Size of Grid [mm]25mm\nHeight with lowest mounting type [mm]51mm\.
Compare prices (1 shop)
| shop | Price | Action |
|---|---|---|
|
26,05 GBP | Go to shop |
