OTL50-2 connector, blue 2xAl/Cu 1.5-50mm2 1000V Universal terminal MAA205 /T2UK

Name: OTL50-2 connector, blue 2xAl/Cu 1.5-50mm2 1000V Universal terminal MAA205 /T2UK
Brand: MOREK

MOREK

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nOTL50-2 connector, blue 2xAl/Cu 1.5-50mm2 1000V Universal terminal MAA205 /T2UK\nParameters:\n\n--CN: 85369010\n-- Blue color\n-- Type of insulating material: Thermoplastic\n-- Flammability class of the insulating material according to UL94: V0\n-- Internal floors bridged: Yes\n-- Electrical connection type 1: Screw connection\n-- Electrical connection type 2: Screw connection\n-- Connection Position: Side/Side\n-- Locking Plate Required: No\n-- Insulating element material: Thermoplastic\n-- Cross-section of the connected single-wire cable [mm2] from: 1.5\n-- Cross-section of the connected single-wire cable [mm2] up to: 50\n-- Cross-section of the connected stranded cable without ferrule [mm2] from: 1.5\n-- Cross-section of the connected stranded cable without ferrule [mm2] up to: 50\n-- Length [mm]: 49\n-- Rated voltage [V]: 1000\n-- Operating temperature range [\u00B0C]: 80\n-- Cross-section of the S
