OJL280A GREEN IN 1XAL/ CU120 OUT 2X35/ 5X16/ 4X10MM² MAB1281G10

PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nOJL280A GREEN IN 1XAL/CU120 OUT 2X35/5X16/ 4X10MM\u00B2 DISTRIBUTION BLOCK\nMorek\nMPN : MAB1281G10\nEAN: 4744397018892\n\nPrice per 1 pc\nTechnical parameters\nParametersValue\nETIM ClassTerminal Strip\nETIM GroupLow voltage switching and control units (automatic)\nCable Cross Section120\nNumber of Poles1\nPCN85369010\nMinimum Order Quantity1.00\n\nProduct Description\n\nMOREK OJL distribution blocks are designed to separate larger cross section lines into several smaller ones. OJL blocks are available in 9 standard versions with nominal connection cross section: \u00D8 OJL135A - 35 mm\u00B2 Al/Cu \u00D8 OJL200A - 70 mm2 Al/Cu \u00D8 OJL280A - 120 mm2 Al/Cu \u00D8 OJL400A - 240 mm2 Al/Cu. The AF and AFS marked blocks are designed to connect (input) flexible MOFLEX 10x25mm busbars or multiple 1x25mm rails. The screws are tightened with a hex key. The blocks can be mounted on a standard.
