Teltonika TSW101000000 TSW101 automotive-dedicated

Teltonika TSW101000000 TSW101 automotive-dedicated

Teltonika Networks

The TSW101 is a plug-and-play automotive switch dedicated to in-vehicle applications. Featuring five Gigabit Ethernet ports, including four with PoE+ support, the TSW101 can power your end devices while connecting them to the Internet. This automotive switch can be powered by 12 V or 24 V car battery, requiring no additional PSU.\nEthernet\nETH: 5 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover\nIEEE 802.3 series standards: 802.3i, 802.3u, 802.3ab, 802.3x, 802.3az\nPOE OUT\nPoE ports: Port 1- 4\nPoE standards: 802.3af and 802.3at Alternative B\nPoE Max Power per Port (at PSE): 30 W\nTotal PoE Power Budget (at PSE): 60 W\nMaximum Ethernet cable length: 100 m\nPerformance Specifications\nBandwidth (Non-blocking): 10 Gbps\nPacker buffer: 128 KB\nMAC address table size: 2K entries\nJumbo frame support: 9216 bytes\nPower\nConnector: 2-pin industrial DC power socket\nInput voltage range: 9 \u2013 30 VDC\nPoE-out input voltage range: 9 \u2013 30 VDC\nPower consumption: Idle:8

Compare prices (5 shops)

Sort: Price: lowest first Price: highest first
shop Price Action
68,40 GBP Go to shop
75,95 GBP Go to shop
75,95 GBP Go to shop
ComputersDeal 76,16 GBP Go to shop
116,10 GBP Go to shop
