MK 2G TV Aerial socket FM Diplexer with Single TV & Secondary BT Output

Name: MK 2G TV Aerial socket FM Diplexer with Single TV & Secondary BT Output
Brand: MK

MK Logic Plus - K3562 WHI - 2g TV/FM + Single TV - Diplexer Outlet + Secondary BT Socket\n\nMK Part Code: K3562 WHI\n\nFrom the Logic Plus Range\n\nThe K3562 WHI is a fully screened non-isolated TV FM Diplexer unit for connection to a single aerial lead with combined TV and FM signals. For use within digital TV systems and interactive TV services\n\nIt also has a separate second single TV outlet for connection to a second aerial lead\n\nFor modern satellite upload requirements, the plate has a single BT secondary phone socket included\n\nRecommended cable type (TV) CT100 (or equivalent) and (Phone) 1/0.5mm 2/3 pair solid conductor with 0.15mm insulation\n\nTriplexer Outlet: TV DC 5-68.5MHz, 174-862MHz; FM 87.5-108MHz; SAT DC-200kHz, 950-2400MHz\n\nManufactured and conforms to the following: BS 3041: 1997, BSEN 60169-24, BSEN 50083, IEC 169-2: 1965, BS 5733: 1995 and BS 6312 Pt2\n\nFull instructions are in the packet\n\nDimensions: 146 x 86mm\n\nFixing Centres: 120.6mm\n\nUnused old s.
