Sealey Pillar Drill Floor 16-Speed 1580mm Height 550W/230V Garage Workshop DIY

Sealey

The Sealey GDM160F is a floor standing pillar drill offering 16 speed settings and professional capability for workshop applications. This industrial-grade machine provides a practical alternative to bench-mounted drills, freeing up valuable workspace while delivering the precision and power required for drilling operations in metal, wood and plastics. Featuring a 550W motor with speeds ranging from 210 to 3340rpm, this pillar drill accommodates diverse materials and drill bit sizes through its 16mm capacity chuck with MT2 taper. The adjustable tilting table with rack and pinion height adjustment allows precise positioning of workpieces, whilst the 330mm swing and 165mm spindle centre to column distance provide ample capacity for larger components. Safety and versatility are prioritised with a no-load voltage switch and locking cover to prevent accidental starting, making this drill fully CE certificated and approved for use in educational establishments and industrial workplaces. The substantial 51kg weight ensures stability during operation, whilst the floor-standing design with 1580mm overall height suits workshops where bench space is at a premium. An optional mortise attachment (Model MA10) extends functionality for woodworking tasks, and the unit is compatible with the GDMX/KC keyless chuck accessory. Features and Benefits: • 16 speed settings from 210-3340rpm for versatility across different materials • Floor standing design saves valuable bench space in busy workshops • No-load voltage switch with locking cover prevents accidental starting • Adjustable tilting table with rack and pinion height adjustment for precise positioning • CE certificated and approved for educational and industrial use • Compatible with optional mortise attachment for woodworking applications Specifications: Base Size: 420 x 250mm Brand: Sealey Collar Diameter: Ø60mm Column Diameter: Ø70mm Drilling Capacity (Chuck Size): Ø16mm Maximum Distance Spindle to Base: 1240mm Maximum Distance Spindle to Table: 790mm Motor Power: 550W Nett Weight: 51kg Number of Speeds: 16 Optional Accessories: GDMX/KC - Keyless Pillar Drill Chuck 16mm Overall Height: 1580mm Speed Range: 210-3340rpm Spindle Centre to Column: 165mm Spindle Nose Taper: MT2 Spindle Travel: 80mm Supply: 230V Swing: 330mm Working Base Surface Size: 210 x 190mm Working Table Surface Size: Ø310mm
