SFX Cat6a F/FTP LSZH ECA 10GIG Network Copper Ethernet LAN Cable Reel 100m Blue

Name: SFX Cat6a F/FTP LSZH ECA 10GIG Network Copper Ethernet LAN Cable Reel 100m Blue
Brand: SFX

SFX

Premium Category 6A shielded (FTP) low smoke and halogen free (LSZH) network cable. Supplied on 100 metre reel and has a solid copper core. It is capable of up to 10 Gigabit ethernet speeds and features double transmission frequency from 250MHz to 500MHz. The cable is tested to meet and exceed the Category 6A standard and is suitable for installation in densely populated buildings such as schools offices and retail units where a halogen free cable is required for fire and building regulations. Features: Individual screened foil twisted pairs Up to 10 Gigabits 500 MHZ Frequency Solid copper conductors Clearly metre marked Low smoke and halogen free sheath Conductor Bare Copper Conductor Diameter (mm) 0.565 0.010 AWG 23 Insulation Thickness (mm) 0.18 Insulation Diameter (mm) 1.088 0.05 Filler Type Cross member Mylar Spiral > =115% Drain Wire Tinned Copper Conductor Diameter (mm) 0.45 +/-0.01 Shielding Al-PET Shield > =115% Nylon Rip-Cord Jacket Type PE Jacket Thickness (mm) 0.60 +/-0.05 Overall Diameter (mm) 7.40 +/-0.30 Sheath Printing: Cat 6 FTP 4PR 23AWG PE ISO/IEC 11801 ANSI/TIA 568C.2 (PO) (m) Reaction to Fire Fca Max Conductor DC resistance @ 20C <95/km Rated Temperature 80C Impedance (1-100MHz) 100 15 Test Standards ISO/IEC 11801 ANSI/TIA 568-C.2 PLEASE NOTE: Solid Core Cat 6a should be terminated into faceplates or IDC RJ45 Plugs.
