Timco Silver Lh115w16b Metal Construction Composite Panel Screws - Hex - Epdm Washer - Self-Drilling - Exterior - Organic 5.5/6.3 X 115 Box 100
TIMCO
Specifically designed to attach composite panel to light section steel (Max. 5mm). Self-drilling point with hexagon head and split thread. ApprovalBS EN 10666 (DIN 7504)Corrosion Rating3 - Urban & industrial areas with a low salt atmosphereDescriptionSpecifically designed to attach composite panel to light section steel (Max. 5mm). Self-drilling point with hexagon head and split thread. Drill Tip Angle degree110Drill Tip Length mm8.00Drill Tip Width mm4.50Effective Thread Length mm41EPDM Washer mm16FinishExterior (Silver Organic)Fixed Washer Dia. mm12.00Head Height mm5.70Head TypeHexIncluded Items16mm EPDM WashersLength mm115MaterialCase & Core Hardened Carbon SteelMax Drilling Thickness mm5.0Max Torque Nm6Min Max Panel Thickness mm65 - 95Pack Dimensions L x W x H mm190 x 130 x 90Pack Weight kg1.792Point TypeSelf-Drilling No.3Product CodeLH115W16BRec RPM1,000 - 1,800Size mm5.5/6.3 x 115Socket Size mm8SubstratesComposite PanelThread Dia. mm5.5 - 6.3Thread TypeDual 60° Self-Tapping.
