Kenable Low Smoke Cat5E Lszh Lsoh Utp Copper Ethernet Network Cable Reel 305M from B&Q

Kenable

Low Smoke Zero Halogen network cables are cables that emit very limited smoke and zero halogen when exposed to high sources of heat and are part of building regulations especially when installing cables in schools and other government buildings. Supplied in feeder box the Low smoke cable Is meter marked and perfect for sending internet signals in offices or installing a network at home. This cable is made from FULL COPPER its perfect for sending network signals and power so also ideal for use with POE / CCTV / VOIP equipment. Solid plain annealed copper conductors 8x Insulated wires formed into 4x pairs cabled together Designed to support horizontal networking applications over channel distances up to 100m Cable meets the specified performance for Cat5e U/UTP Supports all CLASS D applications as defined within ISO/IEC 11801 2nd Edition LSZH (violet) jacket Conductor Solid OFC Strands 8 x 1/0.5mm 2% Conductor CSA 8 x 0.196mm² Cable : diameter 5mm Insulation HDPE 0.19mm thickness Sheath LSZH 0.5mm thickness Capacitance 4.9nF/100m DC resistance @ 20C <9.5 ohms/100m Impedance (1 to 100MHz) 100 15 ohms Return loss >20dB @100m Attenuation <22dB @100m NEXT >35.3dB PSNEXT >32.3dB ELFEXT >23.8dB PSELFEXT >20.8dB Phase delay <570ns Cable colour Lilac Length 305m We always suggest to terminate SOLID cable into faceplates or patch panels. See QS numbers below: Cat 5e Single: QS: 001074 Cat 5e Double: QS:001075 Cat 5e Quad: QS: 001277 Cat 6 Single: QS: 001334 Cat 6 Double: QS: 001335 Cat 6 Quad: QS: 001409.
