50M (164 Ft)4 Way 2 Pair Alarm Cable Tinned Copper Stranded Cctv Panel Contact Pir from B&Q
B&Q
50 Metre 4-way/2 Pair Alarm Cable “ Tinned CopperPLEASE NOTE - Voltage drop should be taken into consideration before installing to ensure suitability particularly if you are going over a long distance at a high current. Sometimes techniques such as doubling/tripling up the cores are used to achieve greater distances.Uses “ Commonly used in security/CCTV installations. Alarm cable can be used in a wide variety of applications such as; connecting to PIR sensors, door/window contacts, linking control panels together and much more. Our quality stranded cable has tinned copper cores and a durable, yet flexible PVC outer insulation making it ideal for any low voltage installations.Core Colours: YellowBlack RedBlue Technical Specification: No. of Cores: 4Number of strands per core: 7Conductor Area CSA (per core): 0.22mm²Diameter Per Core - 0.2mmOuter Diameter of Cable: 3.5mmConductor Material: Tinned copper (high grade)Current Rating: 1AMax Working Voltage: 50V RMSResistance: 98.7 Ohms / KMPVC Jacket Colour: WhitePVC Thickness: 0.5mm.
Compare prices (3 shops)
| shop | Price | Action |
|---|---|---|
|
12,09 GBP | Go to shop |
|
|
12,09 GBP | Go to shop |
|
15,99 GBP | Go to shop |
