50M (164 Ft)2 Core Dmx Lighting Cable Reel Drum Shielded Lead Twisted Pair Stage from B&Q
B&Q
50m DMX Cable - 2 Core ScreenedPLEASE NOTE “ Lengths of 50m & 25m may not be supplied on a reel aspictured.Overview:Commonly used for making up (soldering) DMX cables. You will alsorequire 3 or 5 pin DMX connectors. Once made in your desired length, they canbe used for connecting a lighting console to slave devices. A lightingconsole is the controller for a network of slave devices, such as floodlights,moving lights, strobes and fog machines. This cable is designed for 120ohmas per the DMX specification. Quite often people will use audio cable insteadof DMX cable for DMX applications, this can cause irregularities in the digitalwaveforms.This is not microphone cable. If you want to make XLR cables, not DMX cables,please search our shop for microphone cable or get in touch.Specification:External diameter - 7mmArea per conductor - 0.22mm² - AWG24Conductor make up - 7 Strands @ 0.2mmHigh coverage braid shield - 86 Strands @ 0.11mmResistance - 120ohmTinned copper - Tin resists corrosion & does not oxidise protectingthe copper underneath.Low memory cable - therefore can be coiled and uncoiled easily withoutretaining its coil when laid across a stage for example.
Compare prices (2 shops)
| shop | Price | Action |
|---|---|---|
|
109,99 GBP | Go to shop |
|
109,99 GBP | Go to shop |
