B&Q - Slimline-E V3 Programmable Thermostat For Electric Underfloor Heating16AFloor Sensor Included

Heatmiser

The Heatmiser Slimline-E Programmable Thermostat V3 is designed for electric underfloor heating systems up to 16A. It offers accurate floor and air control with a supplied floor sensor and options for floor, air or combined sensing. The thermostat includes an optimum start self-learning preheat, temperature hold, holiday mode and a key lock to secure settings. Programming options include non-programmable, 5/2 day or 7-day schedules, and the display features a blue backlight that auto‑turns off. Temperature units are selectable between °C and °F, and an adjustable frost protection setting helps prevent freezing. Technical details: switch rating 16A (3,680 W), supply 230 V, temperature range 05–35°C, four heating levels, probe rating 10 kΩ, dimensions 98 x 85 x 13 mm, IP20. The Slimline series is slim and flush-mountable and requires a minimum 35 mm back box for installation. Do not install near direct heat sources and avoid pressing the LCD to prevent damage.
