Durite 0-728-42 40A-50A Mini Heavy-duty Changeover Relay

Name: Durite 0-728-42 40A-50A Mini Heavy-duty Changeover Relay
Brand: Durite

Durite

Durite 0-728-42 40A-50A Mini Heavy-duty Changeover Relay\n24V 40A-50A mini extra heavy duty changeover 5 pin relay.\n--Rated: 40A-50A at 24Vdc.\n--Without fixing bracket.\n--Terminals: two 6.3mm and three 9.5mm blade terminals.\n--Pack Quantity: 1 piece.\nAssociated Parts\n--0-729-04 Durite Heavy Duty Bulkhead Socket for Relays.\nSpecifications\n--Type\nChange over relay\n--Voltage\n24 Volts DC\n--Switching voltage\n75 Vdc maximum\n--Load current\n40/50 Amps maximum\n--Contact material\nSilver alloy\n--Contact resistance\n30m\u03A9\n--Voltage drop\n200mV (at contact rating)\n--Coil operating voltage\n15.6 volt\n--Coil dropout voltage\n2.4 volt\n--Coil current\n0.12 amp\n--Coil resistance\n195\u03A9\n--Temperature range\n-40 to +85\u2103\n--Humidity\n40 to 85% Relative Humidity (RH)\n--Function\nLine changeover\n--Housing\nNylon PA66\n--Terminals\nBrass: 2 x 6.3mm and 3 x 9.5mm\n--Dimensions\nLength 34.5mm, Width 32.5mm and Height 34mm (excluding terminals)\n--Guideline Weight\n35g\nIt
