Durite 0-525-36 LED Marine Oil Pressure Gauge Scale 12/24V With sender unit
Durite
Durite 0-525-36 LED Illuminated Oil Pressure Gauge With 1/8 inch - 27 NPT sender\n--Voltage: 12-24VDC.\n--90\u00B0 sweep dial: 0-10 Bar.\n--Plastic cased.\n--LED illumination choice of White or Yellow\n--Matt black bezel and white figures.\n--Requires 52mm dashboard hole.\n--Large screw collar type fitting.\nAssociated Products\n0-523-89 Replacement sender.\n0-525-86 Durite marine oil pressure sender unit 0-10Bar.\nWiring Gauge\n--Black - to Common Ground (-)\n--Red - to Positive (+)\n--Green - to the sensor unit\n--White - for the White backlight (+)\n--Orange - for the Yellow backlight (+)\nWiring Sender\n--W.L./G to Common Ground (-)\n--S - to gauge\nFitting Instructions\n--Cut a 52mm (2 1/16 inch) diameter panel hole.\n--Save a minimum of 55mm (2 3/16 inches) depth behind the panel to fit the gauge.\n--Remove the fastening ring.\n--Fit cables through the panel hole and insert the connector into the back of the gauge.\n--Insert the gauge through the panel from the front,,
