Blue 16x2 LCD Display Module 1602 HD44780 Arduino Raspberry Pi

Blue 16x2 LCD Display Module 1602 HD44780 Arduino Raspberry Pi

Switch Electronics

Blue 16x2 LCD Display Module 1602 HD44780 Arduino Raspberry Pi\n\nBlue 16x2 LCD Display Module 1602 HD44780 Arduino Raspberry Pi\n\n\u00A35.89\n\nAsk a question\n\nDescription\n\nShipping\n\nAbout Us\n\nDescription\n\nBlue 16x2 LCD module featuring 2 rows consisting each of 16 characters. The module is compatible with the Hitachi HD44780 controller, and is commonly used in Arduino and other microcontroller projects. \n\n--White characters on blue background \n--Supply voltage: 5V DC \n--Module dimensions: 80 x 36 x 11mm \n--Display area: 66 x 16mm \n\nPin No.\nSymbol\nHigh/Low Level\nDescription\n1\nVss\n0V\n0V Ground\n2\nVdd\n5V\n5V Supply Voltage for logic (option +3V)\n3\nVo\nVariable\nOperating voltage for LCD\n4\nRS\nH/L\n4 RS H/L H:DATA L:Instruction code\n5\nR/W\nH/L H\nH:Read L:Write (MPU Module)\n6\nE\nH H->L\nChip enable signal\n7\nDB/0\nH/L\nData bit 0\n8\nDB/1\nH/L\nData bit 1\n9\nDB/2\nH/L\nData bit 2\n10\nDB/3\nH/L\nData bit 3\n11\nDB/4\nH/L\nData bit 4\n12\nDB/5\y

Compare prices (1 shop)

Sort: Price: lowest first Price: highest first
shop Price Action
5,89 GBP Go to shop
