Ener-J Plug And Play Microwave Sensor For Cct Led Bulkhead (Sku: T561)

Name: Ener-J Plug And Play Microwave Sensor For Cct Led Bulkhead (Sku: T561)
Brand: ENER-J

ENER-J

Upgrade your ENER‑J T561 LED Bulkhead effortlessly—no rewiring needed. This plug‑and‑play microwave sensor adds motion and daylight sensitivity to control lighting automatically, reducing energy consumption and improving convenience. Fully adjustable with DIP switches, it’s perfect for lobbies, corridors, utility rooms, and shared spaces. Universal Voltage – Works seamlessly with 110–240 VAC and rated at 230 VAC. Ultra-Low Power Standby – Consumes less than 0.2 W when idle, ensuring energy efficiency. Adjustable Hold Time – Choose from 5 seconds, 1, 3, or 10 minutes to fit your occupancy cycle. Customizable Detection Area – Set coverage to 25%, 50%, 75%, or full 100% using DIP switch controls. Daylight Sensor Built-In – Configurable light threshold: 5 Lux, 10 Lux, 25 Lux, or disabled. Technical Specification SpecificationDetailsModelT563 Microwave SensorInput Voltage230V ACStandby Power< 0.2 WHold Time Settings5 s / 1 min / 3 min / 10 minDetection Area25 % / 50 % / 75 % / 100 %Daylight Threshold5 Lux / 10 Lux / 25 Lux / DisabledDetection Radius≤ 3.5 m at 0.3 m/s; ≤ 2.5 m at 1 m/s (at 3 m height)Detection Angle150°Mounting HeightStandard 3 m (max 5 m)Operating Temp Range–25 °C to +60 °CStorage Temp Range–40 °C to +80 °CHumidity< 85 % RH.
