Cyp 4K Uhd Edid Manager

Name: Cyp 4K Uhd Edid Manager
Brand: CYP

CYP

The RE-EDID-4K22 is designed to manage and manipulate the HDMI/DVI EDID information provided to a HDMI source device by a connected display. EDID contains critical information about the capabilities of the connected display, including audio and video form HDMI input and output with 18Gbps (6G) 4K UHD support HDCP 1.4 and 2.2 compliant Supports HD resolutions up to 3840x2160 @ 60Hz (4:4:4, 8-bit) and 4096x2160 @ 60Hz (4:4:4, 8-bit) Supports 48-bit Deep Colour up to 1080p @ 60Hz Supports four different EDID modes - Read/Write/Emulate/Bypass Read mode - reads the TV/display’s EDID information Write mode - overwrites the TV/display’s EDID information (TV/display needs to be able to support overwrite function) Eight unique sets of EDID settings may be stored via the learning procedure Emulator mode - allows the source device to read the selected EDID information from the unit’s default or learnt EDID memory Bypass mode - allows the source device to read the EDID information from the TV/display directly
