Aluminium Foil Membrane 1.5m x 50m (75 SQ/M)

Trade Store Ltd

Technical Highlights EN 13984 compliant vapour control layer Water vapour resistance: 2.5 × 10¹¹ m²·s·Pa/kg Equivalent air layer thickness (Sd): approx. 50m Reflective aluminium surface provides radiant heat reflection Independently tested reflective performance by the British Board of Agrément (BBA) Applications Suitable for use in a wide range of construction applications including: Timber frame wall systems Masonry cavity walls Insulated pitched roofs Loft conversions Internal insulation systems Floors and ceilings requiring vapour control Underfloor heating floor constructions; installed on the warm side of the insulation. Property Performance Standard Product Type Reflective Vapour Control Layer EN 13984 Water Vapour Resistance 2.5 × 10¹¹ m²·s·Pa/kg EN 1931 Equivalent Air Layer Thickness (Sd ) )~50m EN 1931 Surface Finish Metallised Aluminium Reflective Layer Emissivity 0.47 BBA Tested Tensile Strength MD 220 N EN 12311 Tensile Strength TD 150 N EN 12311 Tear Resistance 100 N EN 12310 Reaction to Fire Class E EN 13501 Installation Guidance The membrane should be installed on the warm side of the insulation layer. The reflective aluminium surface should face an internal air cavity where possible to maximise radiant heat reflection. All joints should be overlapped and sealed using appropriate vapour control tapes to maintain airtightness. Service penetrations should also be sealed. Note – this VCL is not self adhesive and requires mechanically fixing. Certifications and Testing EN 13984 compliant vapour control membrane Declaration of Performance available Reflective surface independently tested by the British Board of Agrément (BBA) Manufactured in accordance with Construction Products Regulation (CPR) Downloads Product Technical Datasheet Declaration of Performance (DoP) BBA Emissivity Test Report Installation Guidance Document.
