12V Mini Changeover Power Relay 20A 5-Pin SPDT

12V Mini Changeover Power Relay 20A 5-Pin SPDT

Meishuo

12V Mini Changeover Power Relay 20A 5-Pin SPDT\n\n12V Mini Changeover Power Relay 20A 5-Pin SPDT\n\n\u00A33.59\n\nAsk a question\n\nDescription\n\nShipping\n\nAbout Us\n\nDescription\n\n 12V changeover relay with SPDT contacts suitable for automotive and general purpose applications. The relay is designed for PCB mounting and has a compact sealed design to protect from dust and water.\n\n--SPDT contacts\n--High resistance to vibrations\n--Coil voltage: 12VDC\n--Coil power: 600mW\n--Maximum switching current: 20A (at 16VDC)\n--Maximum switching voltage: 60VDC\n--Maximum switching power: 280mW\n--Dimensions: 15.25 x 12.25 x 13.6mm\nTechnical Information\nMax Switching Current\n20A\nMax Switching Voltage\n60VDC\nCoil Voltage:\n12VDC\nPick-Up Voltage\n7.3VDC\nContact Arrangement\nForm C (NO/NC)\n Please contact us for a datasheet \n\nShipping\n\nAbout Us\n\nShop related items\n\neBay & Ecommerce Stores By
