Rfx Unisex Red Pro 2 Rear Axle Adjuster Blocks (Orange),

Name: Rfx Unisex Red Pro 2 Rear Axle Adjuster Blocks (Orange),
Brand: RFX

RFX

RFX Pro Series 2 Rear Axle Adjuster Blocks (Orange) KTM 125-525 13-15 RFX Pro Series Axle Blocks are designed to speed up & improve wheel changes with easy fitting and more precise alignment. CNC manufactured from 7075 aerospace grade aluminium. Pro Series Axle Blocks Features:- * Laser etched RFX logo. * CNC 7075 Aerospace aluminium. * CAD designed profile for lightness. * Tighter tolerances for improved fit. * Alignment scales both sides for precision. * Colour anodised for that factory bike look. Fitting Instructions * Start with bike on a stand with the rear wheel raised from the ground. * Undo rear axle nut and remove spindle. * Lift chain of sprockets & remove rear wheel. * Remove old axle blocks. * Remove old axle block bolts. * Remove the spindle from the axle block (KTM Only) to do this may require some heat and a vice, be careful not to damage the spindle. * Re-fit the spindle to the new axle block (KTM Only) make sur to use red threadlock when doing this. * Clean arou...
