Hobby Components As312 Pir Sensor

Name: Hobby Components As312 Pir Sensor
Brand: Hobby Components

Hobby Components

AS312 is a new smart digital motion detector with a small window size. It offers a complete motion detector solution, with all electronic circuitry built into the detector housing. Only a power supply and power-switching components need to be added to make the entire motion switch. AS312 delay time is 2 seconds. Please see item HCSENS0052 for a suitable PIR sensor Specification Supply Voltage: 3V Working Current: 15uA Output Low Current (min): 10mA Output High Current (max): -10mA On-time: 2.3s Features and Benefits Digital signal processing（DSP） Power adjustable, save more energy Two-way differential high impedance sensor input and temperature compensation Built-in filter, screen the interference by other frequency Excellent power supply rejection, Insensitive to RF interference Schmidt REL output, Manufacturer: Hobby Components Ltd
