Compact Single Circuit Remote Brake Servo

Compact Single Circuit Remote Brake Servo

CBS

Compact Single Circuit Remote Brake Servo\nCanister diameter 138mm. Overall length 230mm. Vacuum inlet 3/8\"" (10mm) push-on hose tail. Fluid inlet and outlet female threads 3/8\""UNF. 2:1 power boost ratio at 600mm Hg vacuum. Two M5 mounting studs on cylinder flange and one M8 on rear of canister. Weight 2.05kg. NOTE: THE BLEED SCREWS HAVE AN ACCOMPANYING BALL BEARING SEAL, BE CAREFUL NOT TO LOSE IF SCREW IS REMOVED. (see picture) A mounting bracket is available #SINGBKT COMPACT REMOTE SERVO #REMSERV2\n\nCompact Single Circuit Remote Brake Servo\n\nCanister diameter 138mm.\n\nOverall length 230mm. \n\nVacuum inlet 3/8\"" (10mm) push-on hose tail. \n\nFluid inlet and outlet female threads 3/8\""UNF. \n\n2:1 power boost ratio at 600mm Hg vacuum. \n\nTwo M5 mounting studs on cylinder flange and one M8 on rear of canister. \n\nWeight 2.05kg.\n\nNOTE: THE BLEED SCREWS HAVE AN ACCOMPANYING BALL BEARING SEAL, BE CAREFUL NOT TO LOSE IF SCREW IS REMOVED. (see pictury

Compare prices (1 shop)

Sort: Price: lowest first Price: highest first
shop Price Action
365,70 GBP Go to shop
