Ammeter with Chassis Mounting Panel 7-33VDC A25-1BPS-BB3-R

Name: Ammeter with Chassis Mounting Panel 7-33VDC A25-1BPS-BB3-R
Brand: SCI

SCI

Ammeter with Chassis Mounting Panel 7-33VDC A25-1BPS-BB3-R\n\nAmmeter with Chassis Mounting Panel 7-33VDC A25-1BPS-BB3-R\n\n\u00A317.89\n\nAsk a question\n\nDescription\n\nShipping\n\nAbout Us\nDescription\n\nThe A25-1BPS-BB3-R is a ammeter complete with mounting panel. The meter features 7-33VDC operating voltage and is capable of measuring from 0-20A current. The meter features a red LED display and is protected against reverse polarity and surge protection. The housing allows the meter to be easily mounted to a panel, suitable for 12V and 24V applications including automotive. \n\n--0-20A test range \n--Red LED display \n--Operating voltage: 7-33VDC \n--Reverse polarity protection \n--Surge protection \n--6.3mm quick connect terminals and 14AWG tail leads \n--Mounting hole pitch: 47.5mm \n--Dimensions: 39.4 x 62.8 x 46mm (depth x width x height)\n\nShipping\n\nAbout Us\n\nShop related items\n\neBay & Ecommerce Stores By
