Triax Tfc Fm/Dab/Uhf Masthead Tv Aerial Combiner, Through Line Power, F-Connectors (370683) Gold 5702663706835

Name: Triax Tfc Fm/Dab/Uhf Masthead Tv Aerial Combiner, Through Line Power, F-Connectors (370683) Gold 5702663706835
Brand: Triax

Triax

TRIPLEXER FM/DAB/UHF External Masthead Signal Combiner splitter TV Aerial Triax Diplexer 370683\nTriplexer for FM / DAB / UHF - 3 IN - 1 OUT\nFEATURES:\n--UHF & FM (VHF) & DAB\n--Triplexer / Combiner\n--Masthead Combiners with gold F Connectors\n--Greater electrical connectivity\n--Improves shielding\n--Corrosion-resistant\n--Flip and lock mechanism for easy installation\n--Neoprene soft cable grip\n--Weatherproof housing\n--Can be used internally or externally\n--Full screened enclosure\n--Field proven mast securing methods\n--Supplied with F-Connector tool\nTECHNICAL SPECIFICATIONS\nDimensions:\nHeight 140 mm\nDepth 60 mm\nWidth 18 mm\nConnectors\nNumber of inputs 3\nNumber of outputs 1\nConnector type F-female (Gold)\nInputs\nInput 1 - Band FM\nInput 1 - Frequency 87.5-108 MHz\nInput 1 - Through loss <1.0dB Typ dB\nInput 2 - Band DAB Input 2 - channels 5-12\nInput 2 - Frequency 174-230 MHz\nInput 2 - Through loss <1.5dB Typ dB\nInput 3 - Band UHF\nInput 3 - Channels l
