Residual current circuit breaker 4P 40A 100mA 10kA type B /T2UK

Name: Residual current circuit breaker 4P 40A 100mA 10kA type B /T2UK
Brand: Gacia

Gacia

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nResidual current circuit breaker 4P 40A 100mA 10kA type B /T2UK\nParameters:\n\n--Rated voltage [V] 1: 400\n-- Short-circuit withstand strength (Icw) [kA]: 10\n-- Width in number of modules: 4\n-- Rated current [A]: 40\n-- Number of poles: 4\n-- Rated voltage [V] 2: 415\n-- Sensitivity: B\n-- Mounting method: DIN rail\n-- Degree of protection (IP): IP20\n\nSPECIFICATION: type: B rated current: 40A rated current In: 100mA Rated impulse withstand voltage Uimp: 4.5kV Rated making and breaking capacity Im = I\u0394m: 1000A short-circuit withstand Inc = I\u0394c: 10kA pollution degree: 2 rated voltage Ue: 400 / 415V electrical life: 2000 mechanical life: 4000 position indicator work: yes protection class: IP 20 storage temperature: -30 / + 70 \u00B0 C operating temperature: -30 / + 50 \u00B0 C maximum cross-section of connecting wires: 25 mm2 tightening torque of connection terminals: 3Nm possibility of coS
